The prototyping was started early 2011.
v.0.1.01 - 2011.02.10 - first evaluation version
v.0.1.13 - 2016.10.04 - current release
BIM implementation for Blender is not completed yet (2016.10.04),
the importer creates only geometrical part of BIM data.
List of supported IFC objects: - WALL
- WALLSTANDARDCASE
- SLAB
- OPENINGELEMENT
- WINDOW
- DOOR
- ROOF
- STAIR
- STAIRFLIGHT
- COLUMN
- BEAM
- RAMP
- RAMPFLIGHT
- PLATE
- CURTAINWALL
- RAILING
- MEMBER
- SITE
- SPACE
- BUILDINGSTOREY
List of missing IFC objects: - hierarchies
- relationships
- non-geometrical data
License: GNU-GPL
Download: you will get a copy per email.
Registration: Please send me an email "IFC-importer - registration" including:
- first and last name:
- city and country:
- email-address:
- a few words about you (so i can see you as a real person):
- a few words about your motivation to use Blender:
- your account on blenderartists.org:
- your website:
- Where did you learn about IFC-importer?
Your data will be used only for this registering purpose.
Note: Please support development of IFC-importer through supporting
CADtools project.
Contact: You can contact me per email (subject: "IFC-support").
